IS-1235S Series SMT Type Tiny Slide Switch 系列表面黏著微小的滑動開關

Specification:

產品規格:

• Rating額定電流: 0.3A 6V DC.
• Function功能: ON-ON.
• Travel行程: 2.0±0.3mm.
• Contact resistance接觸電阻: 70mΩ Max.
• Insulation resistance絕緣電阻: 100MΩ Min. at 100V DC.
• Withstand voltage耐電壓: 500V AC for 1 minute.
• Operating force操作力: 200±100g.
• Operating life壽命次數: 10,000 Cycles.
