IT-1182B Series Right Angle Tact Switch  系列90度側壓輕觸開關


Specification:
產品規格:

• Rating額定電流: 50mA 12V DC.
• Full travel行程: 0.15±0.1mm.
• Contact resistance接觸電阻: 100mΩ Max.
• Insulation resistance絕緣電阻: 100MΩ Min. at 100V DC.
• Withstand voltage耐電壓: 100V AC for 1 minute.
• Operating temperature操作溫度: -20℃ ~ +70℃.
• Operating force操作力: 160g±50g.
• Electrical life電氣壽命次數: 100,000 Cycles.
